The Engineering SLA Resin – Heavy Duty is one of the strongest resins on the market. It combines flexural strength with durability and heat resistance. Parts printed with this resin show great resistance to continuous built-up pressure. This resin is perfectly suitable for applications that need strength, stiffness and heat resistance.

Key features

• Flexural strength of 135 MPa
• Stiff and durable
• High heat resistance of 128°C
• High dimensional accuracy and low shrinkage
• Almost odorless processing
• Compatible with all open-source SLA, DLP, and LCD 3D printers in the range of 385 – 405nm

Applications

• Tooling
• Jigs and fixtures
• Manufacturing aids
• Mold masters for low volume injection molding
• Functional prototyping

Resin properties (uncured liquid)

• Viscosity: 550 cps at 25°C
• Density: 1.12 g/cm2

Print Settings:

Anycubic Mono X

50µm
First / Burn-in / Bottom Layers: 2x to 4x for 55 to 60 Seconds
Exposure Time Normal Layers: 4 to 5 Seconds
Lifting Distance: 6mm
Bottom Lifting Distance: 8mm
Lifting Speed:85mm/min & 240mm/min
Rest Time Before Lift: 2 Seconds
UV Power: 100%

Mechanical properties

Test method on post cured objects through 10 minutes high power mercury curing.
