Discover the Shining3D EinScan RIGIL is the world’s first Tri-Mode 3D scanner with built-in computing, wireless solution and hybrid light technology. Rigil offers a fully integrated 3D scanning wireless workflow with three working modes that effectively eliminates the traditional compromise between computing power and flexibility.  It provides high quality models with 0.04 + 0.06 mm/m volumetric accuracy and high geometric resolution up to 0.05mm. Its hybrid light sources — 19+19 crossed blue laser lines, 7 parallel blue laser lines, and infrared VCSEL — which paired with two separate groups of tailored cameras to ensure versatile performance and peak efficiency for objects of wide-range of sizes and surface types.

EinScan RIGIL Key Features

Hybrid light resources : 2 Blue Laser Scan Modes – IR Rapid Scan Mode

• 19+19 crossed laser lines for quick scanning, delivering industry leading efficiency and data quality.
• 7 parallel laser lines for HD scanning, providing consistent results with fine geometric details.
• Infrared VCSEL for marker-free scanning, adapting to rich tasks in diversified working environment.

Above 2 laser modes can switch during scanning process, and respective data merged together, to achieve speed and detail in one scanning project.

• High Volumetric accuracy 0.04+0.06 mm/m;
• Geometric Resolution up to 0.05 mm
• Superior adaptability to scan objects with dark or reflective metal surface without spray
• Working efficiently in sunlight outdoors.
• Marker-Free Laser Scanning
• 5MP Full Color Texture Scanning
• All-In-One Powerful Hardware 1T SSD ROM; 32GB DDR5 RAM Built-in 2* 6000mAh replaceable batteries 6.4” 2K AMOLED touchscreen

Who is this 3D Scanner for?

EinScan Rigil is designed to comprehensively address the 3D modelling needs of the automotive aftermarket for prosumers (professional, producer & consumer). Rigil is the first truly universal 3D scanner engineered to meet the diverse demands of the automotive modification industry.

It significantly enhances efficiency in generating high-quality 3D models, combining fast scanning capabilities, streamlined professional workflows, lightweight computing solutions, and rich data editing functions.

The All-In-One design with Cable-Free, Size-Free experience and strong materials adaptability, makes Rigil capable of scanning anytime anywhere. For users requiring faster speed or finer details, Rigil can also utilise PC Mode with Wireless or wired connection for advanced performance.

What comes with the EinScan Rigil?
