EinScan-Pro handheld 3D scanner +SEdge

Shining 3D

  • £3,995.00
  • Save £0


EinScan-Pro 3D Scanner can rapidly capture the 3D data of the real objects to the computer, including human body as well as freeform surfaces and virtually any object.

EinScan-Pro (Mono) Packages:-

  • Pro Mono scanner
  • Pro Industrial Pack = EinScan-Pro with Automated Turntable & Tripod

EinScan-Pro Specification

Scan Mode: Handheld HD Scan
Version: Basic
Scan Accuracy: 0.1mm
Scan speed: 15 frames/s
Point distance: 0.2mm-2mm
Point distance: 0.03-4.00m
Align mode: Reference point align
Texture scan (Add-on module): No

Scan Mode: Handheld Rapid Scan
Version: Basic
Scan Accuracy: 0.3mm
Scan speed: 10 frames/s
Point distance: 0.5mm-2mm
Part size range (recommended): 0.15-4.00m
Align mode: Feature align
Texture scan (Add-on module): No

High Speed

In handheld scan mode, the scan speed is 10 frames/s.

    High compatibility

    Data output can be used for 3D printing as well as designing directly. Data format: stl, obj, asc.

    More

    EinScan can rapidly capture the 3D data of the real objects to the computer, including human body as well as complex and irregular shapes. EinScan Handheld 3D Scanner has the feature of easily using and the 3D scan software’s user friendliness leads you to finish scanning and realize the operation guided.

    EinScan handheld 3D Scanner has the feature of easily using and the 3D scan software’s user friendliness leads you to finish scanning and realize the operation guided. The weight is only 0.8kg, which is quite light and portable, also fit for long-time handheld 3D scan. EinScan delivers watertight 3D data available to 3D print or reverse engineering directly, meanwhile it can output the unclosed 3D model for reversal design.

    Shipping costs cover import duties.

    SolidEdge ST10 Classic software now included.

    The Applications Covered

    Engineering, Research and Design, Human 3D Scanning, Art, Computer Graphics, Education, Heritage

    High compatibility to 3rd party hardware and software

    The Most Powerful 3D Scanner.

    Full Specification

    Outdoor operation: No (affected by strong light)
    Special scan object: For transparent, reflective and dark objects, please spray powder first before scanning
    Scan Mode: Single scan range 210x150mm
    Light source: White light LED
    Printable data output: Yes
    Data formats: OBJ,STL,ASC
    Scan head weight: 0.8kg
    System support: Win7, Win8, Win10 64bit
    Specification Display card:NVIDIA GTX660 or higher
    Display memory:>2G
    Processor:I5 or higher
    Memory Storage:16G or more
